24V/36V/48V 250w-1000w Brush Electric Motor For E-bike Go Kart Scooter Razor
Specifications
| Return Shipping Will Be Paid By | Buyer |
| Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Colour | Black Silver |
| Material | Aluminium |
| Part Type | Motor |
| MPN | Does Not Apply |
| Compatible Bike Type | Universal |
| Brand | Unite |
| Set Includes | Bottom Bracket |
| Manufacturer Warranty | 1 Year |
| Voltage | 24V 36V 48 V |
Pls note: If you old motor have 2 wires, pls choose brush motor, If it with 3 wire , pls choose brushless motor , package depend on your choose from drop down menu.Brush Motor: 24v 250WRated current: 13.7ANo-load current: ≤1.6AMotor weight: 4.4lbsHorsepower: 0.35HPRated speed: 2650-2950 RPMRated voltage: 24V DCRated current: 13.7APeak efficiency at 24V: 80 percentReversible: (w/ polarity swap) Brush motor: 24v 350 watts (kW) Rated voltage: 24V (V) Rated voltage range of 3C: DC below 36V Rated speed: 2750RPM Rated output power: 350W No load current: 2.0A Rated current: ≤ 18.7A Rated torque: 1.2/N.m Mounting hole spacing: 42-95(4 holes in total) Mounting hole diameter: 5 Cylinder diameter: 100 Sprocket: 11 teeth 25 chains Brush Motor: 24V DC 500w - Max 500 Watt, 26.7 amps - Max 2500 RPM - Chain drive (11 teeth sprocket) #25h chain - Type of motor: DC, Brush - Reversible - 12 gauge leads Brush motor: 36v 350WRated speed: 2650-2950 RPMNo-load current: ≤2.0AMotor weight: 5.7lbs(2.6kg)Horsepower: 0.48HPRated current: 12.6APeak efficiency at 36V: 80 percentReversible: (w/ polarity swap)Note: This motor is capable of rotation in either the clockwise or counterclockwise direction by reversing the motor's power wires. Brush Motor: 36v 800WRated speed: 2750-3045 RPMRated voltage: 36V DCRated current: 29.2ANo-load current: ≤2.6APeak efficiency at 36V: 80 percentReversible: (w/ polarity swap)Sprocket：for 25H chain Brush Motor 36 Volt 500w Rated Speed: 2500RPM Rated Current: 18.3A 11 tooth sprocket for 8mm (T8F) Chain Overall Shaft Diameter: 11.9mm Overall Shaft Length: 23mm Outer Diameter of Motor: 107mm Overall Length: 157mm inkfrog terapeak
