350W Gear Reduction Electric Motor, Electric Bike Motor Kit, Brushless Motor Kit
Specifications
| Part Type | Motor |
| Brand | Unbranded |
| Color | Silver |
| Efficiency | ≥80% |
| Net Weight | 5.89kg/12.99 lbs |
| Gross Weight | 6.2kg/13.67 lbs |
| Controller Voltage | 24V DC |
| Process | Spray Painting |
| Installation Required | Yes |
| Controller Under Voltage | 20V |
| Each Motor Rated Voltage | 24V DC |
| Each Motor Output Power | 350W |
| Each Motor Rated Speed | 330rpm |
| Each Motor Rated Current | 15A |
| Each Motor Protect Grade | IP 33 |
| Controller Max. Current | 16A*2 |
| Controller Rated Power | 350W*2 |
| Motor Unload Current | ≤ 2.2V |
| Motor Unload Speed | 370rpm |
| Motor Rated Torque | 11.6 N·m |
| Mounting Base Size | 10.8*5.5cm/4.25*2.1in |
| Product Size | 10.2*12.8cm/4.02*5in |
| Manufacturer Warranty | 3 Years |
Specifications Color: Silver Material: Aluminum, Iron, Copper Wire Process: Spray Painting Installation Required: Yes Each Motor Rated Voltage: 24V DC Each Motor Output Power: 350W Each Motor Rated Speed: 330rpm Each Motor Rated Current: 15A Each Motor Insulation Class: F Each Motor Protect Grade: IP 33 Controller Voltage: 24V DC Controller Under Voltage: 20V Controller Max. Current: 16A*2 Controller Rated Power: 350W*2 Motor Unload Current: ≤ 2.2V Motor Unload Speed: 370rpm Motor Rated Torque: 11.6 N·m Efficiency: ≥80% Mounting Base Size: 10.8*5.5cm/4.25*2.1in Product Size: 10.2*12.8cm/4.02*5in Package Size: 33*23.5*19.5cm/12.99*9.25*7.68in Gross Weight: 6.2kg/13.67 lbs Net Weight: 5.89kg/12.99 lbs Package Included 2* Electric Motors 1* Motor Controller.
