500RPM 48V 1500W Rear Hub Motor Fat Wheel Thread Brushless Gearless Hub Motor

500RPM 48V 1500W Rear Hub Motor Fat Wheel Thread Brushless Gearless Hub Motor

USD 80.93 USD

SKU: dvwjn3mZ

Brand: Unbranded

GTIN: Does not apply

Condition: New

Tags: 1*motor 13.65x3x35mm 1500W 17mm 243mm 3pcs 40N. M 48 V 48V, 1500W Controller 500RPM 7.8kg Black Fat wheel Unbranded

Categories: Bicycle Components & Parts

Specifications

Color	Black
Brand	Unbranded
Voltage	48 V
Power	1500W
Motor Color	Black
Motor Net Weight	7.8kg
Motor Diameter	243mm
Hall Sensor Quantity	3pcs
Max. Speed	500RPM
Max. Torque	40N.M
Magnet Body Size	13.65x3x35mm
Axle Diameter	17mm
Corresponding Controller	48V 1500W Controller
Package	1*motor

Specification Assembly Required: No Style: Modern Shape: Round Color: Black Material: Aluminum, Iron, Copper, Magnetic steel Voltage: 48V Power: 1500W Motor Type: Brushless Gearless Threaded Hub Motor Number of Hall Sensors: 3 Maximum Speed: 500RPM Maximum Torque: 40N.M Motor Diameter: 242mm/9.53in Magnet Size: 13.65*3*35mm/0.54*0.12*1.38in Axle Diameter: 17mm/0.67in Motor Shaft Diameter: M14(14mm/0.55in) Hub Opening Width: 135-145mm/5.31-5.71in Brake: 6-hole Type Disc Brake ( Not Included ) Corresponding Controller: 48V 1500W Controller Noise Data: <45dB Motor Cable Length: 1.2m/3.94ft Motor Shaft Length: 210mm/8.27in Motor Opening Distance: 135mm/ 5.31in Flat Fork Width Requirement: 135-142mm/5.31-5.
